GM TOPROLL® 10/14

At Glas Marte, in contrast to other systems, the glass panes are held in the upper running shoe by bonding and additionally by a retaining device with bolts. The sliding doors are therefore not held solely by means of bonding or clamping. An exact glass position is thus guaranteed, the panes do not slip. In addition, the glass is supported centrally. The reliable perpendicular support of our glass doors is based on a simple principle: two rollers on two running rails. The guide rail protects against damage. The concealed brush seal ensures a low-maintenance construction, freezing up is impossible. Simple installation is a matter of course with Glas Marte.

Specifications:
2, 3 and 4-track
frameless
glass 10 to 13.5 mm
maximum sliding glass weight: 100 kg
maximum system height: approx. 2,800 mm
