The best of both worlds
9/17/2024
• temperature and water flow control • precise temperature control thanks to vertical handle structure and haptic feedback from the thermostat handle • water flow control with stop function • thermostat cartridge • maximum flow rate at 3 bar: 34,8 l/min • flow rate upper outlet: 32 l/min • flow rate lower outlet: 32 l/min • flow rate by simultaneous use of all outlets: 34,8 l/min • min. operating pressure: 1 bar • max. operating pressure: 10 bar • flat escutcheon for more space in the shower • escutcheon can be aligned by +/- 3° • easy installation due to pre-assembled function block • handles always at the same height regardless of the installation depth of the basic set • Safety stop at 40 °C • temperature limitation adjustable • material button: metal • material handles: metal • connection type: basic set iBox universal 2 (# 01400180)
